Dimension(for reference): Length*Width=2600mmX1000mm

Height of equipment working face:800mm to the ground

Dimension of its product:Width:750mm

Molding material:t=0.35～0.4mm,embossed aluminum sheet

Production takt: About 6 seconds/time; About 15 seconds/piece

Total electric capacity:about 1Kw，220V，50Hz

Total gas capacity:About 0.5  Mpa

The limit deviation accuracy of the unmarked tolerance size of the drawings is according to GB1804-m, roughness of cutting surface,Ra is 2.5-6.3,the burr height of the workpiece should ≤0.15mm
