Dimension:L:800~2000mm,W:450~800mm,D:450~900mm

Curing time:Adjustable within 999s

Curing temperature:Adjustable between 35~70℃

Working stations:6~8

Injection mode:horizontal injecting by single head from the side of the line

Foaming agent:POL(Cycle pentane or141b)+ISO

Cycle time:About 30s/pcs(depend on the curing time and fixture quantity)

Product model:able to process 6~8 different products at the same time

Fixture driven mode:driven by electric motor

Voltage:380V,50Hz

Total power:Max:≤190Kw,control box power:24V

Compressed air supply:1/2"(0.5Mpa) air consumption 0.1m?/min
